Matrix VS-S70 User Manual

8
Parts List
ID
DESCRIPTION
QTY
1 M10 X 125L Socket Head Cap Screw 4
2 M10 Flat Washer 26
3 Wide Cupped Flange 2
4 User Frame 1
5 Lower Connecting Tube 1
6 M10 X 20L Socket Head Cap Screw 10
7 M10 Nylock Nut 11
8 Weight Stack Frame 1
9 Upper Connecting Tube 1
10 Handlebar Assembly 1
11 M10 Flat Washer (Ø18 mm) 8
12 M10 X 30L Socket Head Cap Screw 4
13 Bottom Pad 1
14 Back Pad 1
15 M10 X 75L Socket Head Cap Screw 2
16 Linkage 1
17 M10 X 160L Socket Head Cap Screw 3
18 Exercise Arm Assembly 1
19 Front Shroud 1
20 Rear Shroud 1
21 M8 X 25L SHC 4
22 Large M8 Flat Washer (Ø20 mm) 4
23 Top Cap 1
24 Top Cap Cover 2
PREMIUM KIT COMPONENTS
1P Wing 1
2P Rep Counter 1
3P Towel Hook 1
4P ASG Pull Grip 3
