46
CHAPTER 8: TROUBLESHOOTING
8.1.2 XR UCB Ports Description
A
LCD Display
Port
A
Program Keypad
G
Safety Key
B
Quick Key
H
Digital Interface
C
USB Port
I
GND wire
D
LCD Display Port
J
Hand Grip L
E
Program Keypad
K
Hand Grip R
F
USB Interface
L
Polar Interface
