Matrix XR Service Manual

17
CHAPTER 4: XER /XIR CONSOLE INSTRUCTION
4.1.8 BLUETOOTH (XIR ONLY)*
The XIR console can connect via Bluetooth to one device per category:
 Media Players (Music only)
 Speakers / Headphones
 Heart Rate Monitors
4.1.9 TO CONNECT YOUR COMPATIBLE DEVICE:
1) BLUETOOTH PAIRING can be accessed from the SETTINGS MENU .
2) Turn on Bluetooth on your device and make sure it is discoverable.
3) Touch the appropriate category from the list above. The Bluetooth device should appear to the
right after a few seconds.
4) Touch the device name and follow the onscreen prompts to pair the device. Once paired, the
device name will be highlighted and Bluetooth icon will appear in the top right corner of the
menu bar.
5) Connected Media Players or phones can stream audio in the MY MEDIA APP.
6) You may also connect a Bluetooth Heart Rate Strap.
