1. SPECIFICATIONS AND TECHNICAL DATA
1. NAME OF PARTS (SEE Fig.1)
2. TOOL SPECIFICATIONS
3. FASTENER SPECIFICATIONS
TOOL AIR FITTINGS:
CN55, CN70 and CN80 use a 1/4" N.P.T. male plug. The inside diameter should be .28" / 7mm or larger.
CN100 uses a 3/8" N.P.T. male plug. The inside diameter should be .39" / 9.9mm or larger.
The fitting must be capable of discharging tool air pressure when disconnected from the air supply.
RECOMMENDED OPERATING PRESSURE:
70 to 100 p.s.i. / 5 to 7 bar. Select the operating air pressure within this range for best fastener performance.
DO NOT EXCEED 120 p.s.i. / 8 bar.
ENGLISH
OPERATING INSTRUCTIONS MANUAL
1 Frame 5 Magazine
2 Cylinder Cap 6 Trigger
3 Contact Arm 7 Grip
4 Nose 8 Exhaust Cover
PRODUCT NO. CN55 CN70 CN80 CN100
HEIGHT 11-1/8" (283 mm) 12-7/16" (315mm) 14-1/4" (362 mm) 16-3/8" (417 mm)
WIDTH 5-1/8" (131 mm) 5 (128 mm) 5-3/16 (132mm) 6-1/8" (156 mm)
LENGTH 10-5/8" (270 mm) 12-1/16 (306 mm) 12-1/8" (307 mm) 13-1/4" (336 mm)
WEIGHT 5.5 lbs. (2.5 kg) 7.6 lbs. (3.5 kg) 8.2 lbs. (3.7 kg) 11.6 lbs. (5.3 kg)
LOADING CAPACITY 300 to 350 Nails 225 to 300 Nails 300 Nails 400 Nails
RECOMMENDED
OPERATING PRESSURE
70 to 100 p.s.i.
5 to 7 bar
AIR CONSUMPTION 0.032 ft3 at 90 p.s.i.
operating pressure
(0.92L at 6 bar operating
pressure)
0.052 ft3 at 90 p.s.i.
operating pressure
(1.48 L at 6 bar operat-
ing pressure)
0.061 ft3 at 90 p.s.i.
operating pressure
(1.74 L at 6 bar operat-
ing pressure)
0.11 ft3 at 90 p.s.i.
operating pressure
(3.15 L at 6 bar operat-
ing pressure)
PRODUCT NO. CN55 CN70 CN80 CN100
NAIL LENGTH 1" to 2-1/4"
(25 to 57 mm)
1-3/4" to 2-3/4"
(45 to 70 mm)
2" to 3-1/4"
(50 to 83 mm)
2-1/2" to 4"
(65 to 100 mm)
SHANK DIAMETER .083" to .092"
(2.1 to 2.3 mm)
.092" to .113"
(2.3 to 2.9 mm)
.099" to .131"
(2.5 to 3.3 mm)
.099" to .131"
(2.5 to 3.3 mm)
SHANK TYPE Smooth, Ring, Screw
HEAD DIAMETER .197" to .224"
(5.0 to 5.7 mm)
.224" to .275"
(5.7 to 7.0 mm)
.236" to .295"
(6.0 to 7.5 mm)
.256" to .295"
(6.5 to 7.5 mm)
COLLATION ANGLE 15 degree
