Positive Displacement Flow Meters
Helical Rotor Type, H-Series
* See temp chart in product manual.
** Receiver portion of 2 part transmitters are not rated Ex-Proof, consult factory.
† Not available for hazardous location use. (Exceeds 130°C temp. limit.)
Product includes single directional calibration; bi-directional calibrations for Analog and Quadrature devices are optional.
ANSI Flanges supplied by customer.
an ISO 9001:2015 certified company
Flow Meter Selections Transmitter Selections
Model #
/ /
0
-
Non-Standard Options
Bi-Directional Cal: BID
0 Transmitter Type
Max Flow Range Output Type
189 Liters/Min H241 LS 1 A A 4-20mA Output - Powered by 24 Vdc
189 Liters/Min H241 MS 5 A B 4-20mA Output - Powered by 12 Vdc
A C 0-10 Volt Output - Powered by 24 Vdc
500 Liters/Min H242 LS 1 A D 0-10 Volt Output - Powered by 12 Vdc
500 Liters/Min H242 MS 5 P N 5V Pulse - Powered by 5-26 Vdc
Q N 5V Quadrature - Powered by 5-26 Vdc
P S Current Sinking, Single Phase
Pressure Temperature Rating
500 psi (35 bar) LS 1 90°C Industrial / 75°C Haz-Loc
3500 psi (245 bar) MS
2 130°C Haz-Loc Only, 2 Part **
Includes Flange Bolt Kit (see below)
3 225°C Industrial, 2 Part †
Fluid Connection Electrical Connection
NPT 1 1 Industrial, Turck® Connector
Wafer-Mounted Between Customer’s Flanges
5 2 Hazardous Location, 1/2 Inch Conduit*
Seal Selection Signal Type
Viton® - FKM 1 P Pulse
Te on® - PTFE 3 A Analog
Per uoroelastomer - FFKM 5 Q Quadrature
Options Flange Bolt Kit Details
None NA
Model H241 Bolts 3500 psi Bolt Kit for 2500 lb. ANSI Flanges
Heat Trace Option HT
Model H242 Bolts 3500 psi Bolt Kit for 1500 lb. ANSI Flanges
