H-Series User Manual Rev2021A 5
Mechanical - Operation
Determine that the following parameters of your ow metering system are within the specications for the specic
meter being used:
Maximum System Pressure (Specications)
Differential Pressure across meter (Pressure Drop Curves)
Maximum Flow Rate (Pressure Drop Curves)
Metered Fluid Temperature (Sales specication, transmitter specications page 9)
If the metered uid is greater than 28°C (80°F) over ambient, see the “High Temperature Start Up” section below.
With valves (#1) and (#2) closed, slowly open valve (#3) (bypass) to clear the lines of foreign particles and air.
Slowly open the inlet valve (#1). Slowly open the outlet valve (#2). Completely close the bypass valve.
No routine maintenance, cleaning, or lubrication of the ow meter is required. A routine lter cleaning schedule should
be established. The system should be shut down if abnormal noises occur or if unusual differential pressures across the
meter are encountered.
High Temperature Start Up: For uids above 82°C (150°F) based on 21°C (70°F) ambient, a special procedure is required
to prevent thermal shock and permanent damage to the ow meter. The warm up time is determined by the equation
below:
TIME (minutes) = connector size (inches) x (operating temperature (°F)-125)
10
— OR —
TIME (minutes) = connector size (inches) x (operating temperature (°C)-52)
10
Valves (#1) and (#2) must be closed. Open the bypass valve (#3) in gradual steps until the bypass piping is stabilized at
operating temperature. Open valve (#1) slightly and allow the temperature to stabilize around the ow meter. Valve (#1)
can then be opened completely.
Open valve (#2) slightly. The ow meter may make unusual noises or bind at this point. Leave the valve at this setting
until normal meter operation occurs, at which point valve (#2) can be gradually opened all the way. Slowly close the
bypass valve (#3).
