Max NF665/15 User Manual

11
ALWAYS-disconnect air supply before adjusting adjustment
dial.
1 If an adjustment is required, disconnect air supply.
2 Refer to the figure for direction to turn the dial.
3 Reconnect air supply.
THE CONTACT TIP
ALWAYS-disconnect air supply before setting the contact tip.
Set the contact tip on the top of the contact arm, when driving
nails to a soft material.
Use the contact tip at the back of the rear side of the magazine
as necessary.
CLEARING JAMMED NAILS
ALWAYS-disconnect air supply before clearing jammed nails.
1 Disconnect the air hose.
2 Remove the set of nails from the magazine.
3 Open the Latch Cover, then pull up to open the Driver Guide
A.
4 Clear the nails-jammed inside the driver guide using a thin
iron bar or a flat-blade screw driver.
5 Close the Driver Guide A and the Latch Cover.
WARNING
Contact tip
Contact tip
WARNING
Latch Cover
Driver Guide A
WARNING

Max NF665/15 Specifications

General

Brand	Max
Model	NF665/15
Category	Nail Gun
Language	English
