11
<Battery pack>
3. WIRE SPECIFICATIONS
BATTERY CHARGER:
Use only an authorized Battery charger, MAX JC928.
4. TECHNICAL DATA
1 NOISE
A-weighted single-event ------ LWA, 1s, d 86 dB
sound power level
A-weighted single event ------ LpA, 1s, d 76 dB
emission sound pressure
level at work station
These values are determined and documented in accordance to EN12549 : 1999.
2 VIBRATION
Vibration characteristic value - 1.8 m/s
2
These values are determined and documented in accordance to ISO 8662-11.
This value is a tool-related characteristic value and does not represent the influence to the hand-
arm-system when using the tool. An influence to the hand-arm-system when using the tool will, for
example, depend on the gripping force, the contact pressure force, the working direction, the adjust-
ment of main supply, the workpiece, the workpiece support.
3 RADIATED EMISSION 30-1000 MHZ
Class B
Product name MAX lithium ion battery pack
Product code JPL914
Battery type Lithium ion battery
Nominal voltage DC14.4 V (3.6V × 4 cells)
Nominal capacity 3.0 Ah (3,000 mAh)
Charging time
(When charger JC928 is used)
Quick charging - Approximately 30 minutes (Approximately 90%
of capacity)
Full charging - Approximately 45 minutes at 77
°
F (100% of capacity)
Accessories Pack cap (For preventing short circuit)
Weight 1.1lbs
Charging temperature 41°F to 104°F (5°C to 40°C)
Operating temperature 14°F to 104°F (-10°C to 40°C)
Operating humidity 80% RH or less
NAME MAX TIE-WIRE
MODEL TW897A
DIAMETER 21GA. (0.8 mm)
LENGTH 312feet/coil
TIES PER COIL RB397 Approx. 120 ties/coil
TIES PER CHARGE Approx. 1400 ties/charge
