12
w
Remove the Switching Lever to the direction of the arrow.
NOTE:
When switching back CONTACT ACTUATION with ANTI-DOUBLE FIRE MECHANISM to SINGLE
ACTUATION, equip the Switching Lever facing “S” mark front with the Spring Pin to the Trigger by
reverse procedure.
Switching Lever
Spring Pin
●
Use sintering steel grey metallic color Switching Lever
Confirm and use the designated original Switching Lever when carrying out the switching back procedure.
The use of Switching Lever other than the designated original one will cause serious accidents. (e.g., firing fasteners
just pulling trigger, etc.)
WARNING:
Color Shape (1/1 scale) Tool
STEEL BLACKENING HS90A
Projection Shape Flat Shape
This model Previous model
●
Never install the Switching Lever to the Previous model
It will cause serious accidents. (e.g., firing fasteners just pulling trigger, etc)
SINTERING STEEL
GREY METALLIC
NF550
SN883 with thin trigger
STAINLESS SILVER SN883 with thick trigger
To Next Page
