MAXA i-290 0109 - Ground Installation in a Corner

i-290 Inverter air/water heat pumps with axial fans
19
MODEL i-290 X Y L1 L2 D d
 mm 1000 1500 3105 4105 400 250
0112 / 0115 /

mm 1500 2000 4105 5105 400 250


C d
D
C
X
Y
Y1
X1
Bd
D
B
X1
Y1
Y
X
