Fender and Headlight
Step 5: Install the front fender
and headlight
1.Remove the headlight mounting bolt from the fork
arch and set aside.
2.Attach the headlight to the fork arch. Pass the
headlight mounting bolt through a washer, the
headlight mount, the fork arch mounting point, a
second washer, and thread the locknut onto the bolt
end. Use a 5 mm allen key at the bolt head and a
10 mm wrench on the locknut at the bolt end and
tighten partway. Torque all mounting bolts to the
recommended torque value (6 Nm).
3.Behind the mounting bolt, there is a nut in the
middle to hold it firmly. Pls check the pic as below.
4.Connect the cable and turn the headlight on to
test it.
