- LINE VOLTAGE is more than 10% above or below the nameplate voltage rating.
For heavy loads, the voltage at motor terminals must equal the voltage specified
on the nameplate.
- IMPROPER or dull saw blades are used.
• Most motor troubles may be traced to loose or incorrect connections, overload,
low voltage or inadequate power supply wiring. Always check the connections, the
load and supply circuit if the motor doesn’t run well. Check minimum gauge for the
length of cord you are using on the chart below.
GUIDELINES FOR EXTENSION CORDS
• Use a proper extension cord. Make sure your extension cord is in good condition.
When using an extension cord, be sure to use one heavy enough to carry the current
your product will draw. An undersized cord will cause a drop in line voltage, resulting
in loss of power and cause overheating. The table below shows the correct size to
use depending on cord length and nameplate ampere rating. If in doubt, use the next
heavier gauge. The smaller the gauge number, the heavier the cord. Be sure your
extension cord is properly wired and in good condition. Always replace a damaged
extension cord or have it repaired by a qualified person before using it. Protect your
extension cords from sharp objects, excessive heat and damp or wet areas.
• Use a separate electrical circuit for your tools. This circuit must not be less than a
#12 wire with a 20 A time-lag fuse or a #14 wire with a 15 A time-lag fuse.
NOTE: When using an extension cord on a circuit with a #14 wire, the extension cord
must not exceed 25 feet in length. Before connecting the tool to the power line,
make sure the switch is in the OFF position and the electric current is rated the same
as the current stamped on the motor nameplate. Running at a lower voltage will
damage the motor.
SAFETY GUIDELINES
CAUTION!
• In all cases make certain the receptacle in question is properly grounded.
If you are not sure, have a certified electrician check the receptacle.
MINIMUM GAUGE FOR EXTENSION CORDS (AWG)
(when using 120 V only)
Amperage rating Total length of cord in feet
More than Not more than
25’ (7.6 m) 50’ (15 m) 100’ (30 m) 150’ (45 m)
0 6
18 16 16 14
6 10
18 16 14 12
10 12
16 16 14 12
12 16
14 12 Not Recommended

Maximum 055-6767-0 Specifications

General

Brand	Maximum
Model	055-6767-0
Category	Saw
Language	English
