17
TOOLS NEEDED FOR ASSEMBLY
Blade wrench
Supplied
Not supplied
Star-head screwdriver
Adjustable wrench
Combination square Slotted screwdriver
COMBINATION SQUARE MUST BE TRUE
Should not gap or overlap when square is flipped over (see dotted figure).
Should not gap or overlap when square is
flipped over (see dotted figure).
Draw light line on
board along this edge.
Straight edge or a 3/4" board—this
edge must be perfectly straight.
5 mm hex wrench
