12
SVENSKA
5.3 Baksidan
No. Namn FUNKTION
1 LOOP OUT Genomgång för kabelsignal
2 CABLE IN Ingång för kabelsignal
3 VIDEO Video Composite Utgång
4 AUDIO L Audio Utgång vänster
5 POWER AC Strömbrytare
6 EXT. IR Ingång för extern IR-Sensor (Original del)
7 S/PDIF opt. Digital Audio Utgång optisk
8 USB USB 2.0 Port
9 12V OUT 12V Utgång
10 AUDIO R Audio Utgång Höger
11 HDMI High-Definition Digital Video/Audio Utgång
12 DV 12V = 3A Anslutning för extern nätdel
