page 6
Tuning in
The tune and scan buttons
To see what stations are in the station list, press
the TUNE+ or TUNE– buttons to scroll up or down the list.
The station names will appear one at a time on the bottom
line of the display.
When you see the name of the station you want to listen
to, press the SELECT button.
To add new stations to the station list, press the SCAN button a short press for a local
(UK) Scan, a long press (two seconds) for a full (all band III stations) scan. When all
available stations are found, the radio will add them
to the station list, then retune to the station you were
listening to.
If no stations are found, the radio will present a menu
that enables you to perform another scan, or to tune the radio manually. (see page 9)
Tuning to a preset station
Press the PRESET button for the station you wish to listen to.
Note – The first time you switch your new radio on, or straight after
a Factory Reset (see page 11), there will be no preset stations
saved.
TUNE...
SELECT...
Assigning a station to a preset button
Tune to the station that you want to save.
Press the PRESET button that you wish to use for this
station, and hold it in. Wait until the message “Preset
saved” is displayed, then release the button.
When you are scrolling through the station list, any
preset stations will be marked with their preset number.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Maximum DAB Tuner + and is the answer not in the manual?

Maximum DAB Tuner + Specifications

Power IconPower
power supply voltage6V
power supply current500mA
Frequency IconFrequency
quick scan frequency range11B 218.640MHz to 12D 229.072MHz
full scan frequency range5A 174.920MHz to 13F 239.200MHz
