30
AUTO CART STOP OPEN
FIG. 30-1
2. Stand in the footprint area
as shown (FIG. 30-1) before
raising the platform.
NOTE: Auto cart stop is opened
by raising the platform
(FIG. 30-1).
UNLOADING PLATFORM AT BED LEVEL
(AUTO CART STOP OPEN)
FIG. 30-2
3. Raise the platform to bed
level (FIG. 30-2). Move the
load off the platform into the
vehicle body (FIG. 30-2).
VEHICLE
BODY
PLATFORM
USING AUTO CART STOPS (IF EQUIPPED)
- Continued
AUTO CART
STOP
