31
Pulling the load from vehicle to platform can result in a fall from
platform and serious injury. When unloading vehicle, always
push the load out on the platform.
WARNING
!
AUTO CART STOP CLOSED
FIG. 31-2
5. Unload platform with auto cart
stop at ground level as follows.
Move load off the platform as
shown in FIG. 31-2.
NOTE: When loading the platform
at bed level, auto cart stop
is open (FIG. 31-1).
LOADING PLATFORM AT BED LEVEL
(AUTO CART STOP OPEN)
FIG. 31-1
PLATFORM
AUTO
CART STOP
AUTO CART
STOP
NOTE: Auto cart stop is closed
when platform is on the
ground (FIG. 31-2).
VEHICLE
BODY
4. Push load out of the ve-
hicle and place all loads
as close as possible to the
edge of the cart stop(s)
as shown in FIG. 31-1.
If standing on platform
with the load, stand in the
footprint area shown and
comply with the WARNING
shown above.
