Maxon DMD series - Stowing the Platform; Raising Platform for Stowing; Folding and Locking Flipover

19
1. Use outboard control
switch to raise (UP)
platform to comfortable
height (12“ to 18”) above
ground level (FIG. 19-1).
2. Fold and lock fl ipover (if
equipped) (FIG. 19-2).
FIG. 19-1
FIG. 19-2
NOTE: Ensure platform is stowed under hydraulic pressure.
STOWING PLATFORM
FLIPOVER
LOCK
OUTBOARD
CONTROL
SWITCH (UP)
