5. Use outboard control

switch to raise (UP)

platform (FIG. 21-1) to

clear transit hooks (FIG.

21-1A). Final platform

resting position is shown in

FIG. 21-1B.

RAISE PLATFORM

FIG. 21-1

OUTBOARD

CONTROL SWITCH

(UP)

PLATFORM

TRANSIT

HOOK

FIG. 21-1B

FIG. 21-1A
