Page 3 of 36 M-21-08 REV.B
Installation Supplement
Purkey’s Severe Service Charge Line Connections in Battery Box
CIRCUIT BREAKER
FROM PURKEY KIT
JUMPER CABLE
CONNECTS TO PUMP
ASSY SELECTOR
SWITCH
CONNECTS TO J-BOX
12V STUD TERMINAL
CONNECTS TO J-BOX
GROUND STUD
TERMINAL
