Chapter 3: Locations
Exterior Views
Hull Views
GARBOARD
DRAIN PLUG
STERN EYE
TRANSOM
STARBOARD HULLSIDE
PORT HULLSIDE
STERN EYE
DASH
DRAIN
BILGE PUMP
DRAIN
BOW EYE
WASTE TANK VENT
(2100SC ONLY)
ANCHOR
LOCKER
DRAIN
(2100SC
ONLY)
