16 CHAPTER 3: LOCATIONS
Component Locations
12-Volt Accessory Outlet: At the helm, on the dash panel.
Battery:
• All models except the 1750SR: On the port side of the engine compartment.
• 1750SR: On the starboard side of the engine compartment.
Battery Switch (If Equipped): Access is through the hatch behind the port jump seat.
Bilge pump: In the engine compartment.
Carbon Monoxide Detector (2100SC Only): In the V-berth, on the starboard aft wall.
Depth Sounder Transducer (If Equipped): In the engine compartment.
Engine Circuit Breaker: On the engine.
Fuel Fill Deck Fitting:
• All models except the 1750SR: On the starboard aft corner of the deck.
• 1750SR: On the port aft corner of the deck.
Fuel Tank: In the engine compartment, forward of the engine.
Navigation Lights: Red and green bow lights on the forward deck. White all-around light on the stern.
