Chapter 3: Locations
34
Fuse Block - 2100SC: Access is
through the access panel in the cuddy
cabin on the starboard aft wall.
Fuse Block - 2200SR: Access is under the
helm dash.
Navigation Lights: Red and green lights
at the bow. White all-around light on the
transom.
ACCESS PANEL
TYPICAL FUSE
BLOCK LOCATION
