28
Position to mount the rollers in:
I, K, K L, M, N, O, P, Q
Note:
M and N are to be attached to the single roller holder (44)
already assembled in Step 4.
Roller sequence in the traction cable assembly (59):
Guide frame, right (55) - H - I - J - K - L - N - O- P - Q - R - T – guide frame, left (54)
Assembly – Multipress
Single Roller Holder (44)
