Maxxus Multipress 10.1 User Manual

12
13
12
61
60
62
64
61
66
64
66
61
62
30
Assembly – Multipress
Assembly Step 13
Fix four barbell sleeves (61) onto the appropriate mounts on the right and left-hand side frames. To do this use for each
barbell sleeve (61); 2 hexagonal head screws M12x30 (60), four washers Ø12 (12) and two safety nuts M12 (13).
Place one spring clip (62) on each barbell sleeve (61). These will later be used to prevent the dumbbell plates from slipping
down or falling.
