15
button is pressed, the drain pump will be turned on. This output will remain on until the
“Rotary Cycle Selector” button is pressed again to turn off the output.
• Pressing the “Delay” switch pad will turn on the motor and the “Delay” LED. This output and
the LED will remain on until the “Delay” switch pad is pressed again to turn off the output.
When activated, the machine will tumble for 5 seconds in the CW direction, pause for
2seconds, tumble in the CCW direction for 5 seconds, pause for 2 seconds; repeating this
pattern until “ Delay” button is pressed again to turn off the tumbling. Note that all tumble
speeds are assumed to be 45 rpm.
• Pressing the “Chime” switch pad will unlock the door and turn on the all the LED’s above the
“Chime” button. This output will attempt to unlock one time, if safe to do so.
• Pressing the “Temperature” switch pad will lock the door and all the Temperature LED’s will
turn ON. Pressing the “Chime” button will unlock the door and the all the Chime LED’s will
turn ON.
• When the “Rotary Cycle Selector” is set to “Colors” and the “Rotary Cycle Selector” is
pressed, the bleach valve and the cold water valve will be turned on to check the fabric
softener fill. This output will remain on until the “Rotary Cycle Selector” button is pressed
again to turn off the output. The control will not allow the machine to fill past the High water
level.
• When the “Rinse & Spin” keypad is pressed, the Heater will be turned on if the water level is
above the Heater Safety Level. If the water level is below the Heater Safety Level, a warning
beep will be given and the heater will not be turned on. The Heater output will remain on until
the “Rinse & Spin” keypad is pressed again to turn off the output.
Selection Component Function
Rotary cycle selector set to Super Wash.
Press Rotary Selector Knob.
Main Relay
On to Off or
Off to On
Rotary cycle selector set to Normal. Press
Rotary Selector Knob.
Hot Water Valve
1
st
press valve on. 2
nd
press valve
off.
Rotary cycle selector set to Wrinkle
Control. Press Rotary Selector Knob.
Cold Water Valve
1
st
press valve on. 2
nd
press valve
off.
Rotary cycle selector set to Delicates.
Press Rotary Selector Knob.
Bleach Valve
1
st
press valve on. 2
nd
press valve
off.
Rotary cycle selector set to Hand Wash.
Press Rotary Selector Knob.
Pre Wash Valve
1
st
press valve on. 2
nd
press valve
off.
Rotary cycle selector set to Quick Wash.
Press Rotary Selector Knob.
Drain Pump
1
st
press Drain Pump on. 2
nd
press
Drain Pump off.
Press Delay switch pad
Motor
1
st
press Motor on. 2
nd
press Motor
off.
Press Chime switch pad Door Lock 1 Attempt to unlock
Press Temperature switch pad Door Lock Lock Door
Rotary cycle selector set to Colors. Press
Rotary Selector Knob.
Bleach Valve and
Cold Water Valve
1
st
press Fabric Softener fill. 2
nd
press valves off
Press Rinse & Spin switch pad
Heater
1
st
press heater on. 2
nd
press heater
off.
