LED
Display
Description Diagnostic code
E2
Detected a key pressed more than 30seconds, the key
will be assumed to be stuck.
15
dc
Never exceeded 400rpm due to an unbalanced load. 10
od
The door has not been opened after two complete wash
cycles. Door switch was not seen open since the last two
final spins.
17
dL
Open door lock switch with motor running. 18
dS
Door switch is read as open and the door locked switch
is read as locked.
22
bE
Motor tach signal exists without motor running. 25
tE
Abnormal high/low temp or ohm resistance seen. 29
E3
Machine control is attempting to drive the motor but is
not seeing any tach response. Visual check shows motor
is not moving. (Locked, Hall Sensor fault)
2E
Sr
System Relay failure. 34
Hr
Heater Relay failure. 36
3E
Over Current is detected. Motor won't turn. 3E
2E
Voltage for motor control bus is over specified limit. 91
2E
Voltage for motor control bus is under specified limit. 92
Slide 3
Service Mode
Service Mode enables service personnel to verify the operation of the washing machine and
diagnose problems. Service Mode can be entered in the middleof any wash cycle without
interrupting the cycle. While in Service Mode, the technician can cancel the current cycle,
set a continuous running mode, start a variety of special service tests and view diagnostic
displays
