Maytag MFW 9600S User Manual (English)

Questions and Answers:

K
Kathy WattsAug 20, 2025
Why does my Maytag MFW 9600S take so long to drain?
- H
  hutchinsonginaAug 20, 2025
  If your Maytag washer is taking longer than eight minutes to drain, it could be due to several reasons. Check the drain hose to ensure it is not plugged or kinked. Also, inspect the electrical connections at the pump to confirm the pump is running. Examine the drain pump filter for any foreign objects. If these steps don't solve the issue, the pump may need to be replaced. Press PAUSE/CANCEL two times to clear the display.
B
Brittany DanielsAug 23, 2025
How to fix a suds lock on my Maytag MFW 9600S Washer?
- T
  Terry JordanAug 23, 2025
  If your Maytag washer has a suds lock, indicating too much detergent was used, try running the unit through a Rinse/Spin cycle or a Normal cycle without adding any detergent to clear the excess detergent. Also, check the drain hose to ensure it is not plugged or kinked. Inspect wire harness connections to the drain pump, pressure switch, and Central Control Unit (CCU). Check and clean the drain pump filter for any foreign objects. Check the drain pump and the pressure switch. You can also verify CCU operation by running a Diagnostic test or any cycle.
K
Kenneth ClarkAug 26, 2025
What to do if my Maytag Washer displays a door lock error?
- A
  Alexandria MyersAug 26, 2025
  If your Maytag washer shows a door lock error, check the door switch/lock unit because the door lock mechanism might be broken or removed from the door. Also, check the wire harness connections to the door switch/lock unit and Central Control Unit (CCU).
B
Brian MooreAug 28, 2025
What to do if my Maytag MFW 9600S Washer is overflowing?
- B
  Brandon PierceAug 28, 2025
  If your Maytag washer is experiencing an overflow, check the drain hose to ensure it is not plugged or kinked. Inspect the wire harness connections to the drain pump, pressure switch, and Central Control Unit (CCU). Also, check and clean the drain pump filter for any foreign objects. Further, check for drain pump failure. Check the inlet valve for proper shut off and the pressure switch for proper operation.
B
Bradley BonillaAug 30, 2025
What does EEPROM error mean on my Maytag Washer and how to fix it?
- M
  Michael WatsonAug 30, 2025
  An EEPROM error on your Maytag washer might be due to a power glitch. Try unplugging the washer or disconnecting power for two minutes. You can also verify CCU operation by running a Diagnostic test or any cycle.
H
hammondchristinaSep 2, 2025
What causes a door unlock error on a Maytag MFW 9600S Washer?
- C
  christopher28Sep 2, 2025
  A door unlock error on your Maytag washer could be due to a broken door lock mechanism. Check the door switch/lock unit for any foreign objects. Also, check the wire harness connections to the door switch/lock unit and Central Control Unit (CCU).
O
owoodsSep 4, 2025
How do I troubleshoot a Motor Control Unit (MCU) error on my Maytag Washer?
- R
  Ryan OnealSep 4, 2025
  To troubleshoot a Motor Control Unit (MCU) error on your Maytag washer, start by checking the wire harness connections between the drive motor and the Motor Control Unit (MCU), and between the MCU and the Central Control Unit (CCU). Then, check the MCU by looking for operations of the drive motor and check the drive motor for powered rotations.
V
victorbrownSep 7, 2025
What should I do if my Maytag MFW 9600S Washer shows a drive motor tachometer error?
- T
  Tom RothSep 7, 2025
  If your Maytag washer displays a drive motor tachometer error, first verify that the shipping system, including shipping bolts, spacers, and cables, has been removed. Then, check the wire harness connections between the drive motor and the Motor Control Unit (MCU), and between the MCU and the Central Control Unit (CCU). Check the MCU by looking for operations of the drive motor and check the drive motor for powered rotations.
S
Stephen HarrisonSep 9, 2025
Why is the Motor Control Unit (MCU) heat sink tripping on my Maytag MFW 9600S Washer?
- E
  Erin WhiteSep 9, 2025
  If the Motor Control Unit (MCU) heat sink is tripping on your Maytag washer, check for proper installation and ensure the unit is not near a heat source and has proper ventilation. Inspect the wire harness connections to the MCU, the motor, and Central Control Unit (CCU). Also, check the drive system for any worn or failed components. Check the MCU by looking for operations of the drive motor and check the drive motor for powered rotations.

Maytag MFW 9600S Specifications

General

Brand	Maytag
Model	MFW9600S
Type	Front Load Washer
Energy Star Certified	Yes
Steam Function	Yes

Summary

Forward

Goals and Objectives

Outlines the purpose and learning outcomes of the job aid.

General Information

Safety First

Details safety precautions and symbols for safe operation.

Model and Serial Number Designations

Label Locations

Specifications

Maytag Major Appliance Warranty

Installation Requirements

Tools and Parts

Lists necessary tools and supplied parts for washer installation.

Optional Accessories

Describes optional accessories like pedestals and stack kits.

Location Requirements

Installation Clearances

Specifies required spacing around the washer for installation and servicing.

Washer Dimensions

Provides the physical dimensions of the Maytag Epic washer.

Drain System

Drain System Types

Covers standpipe, laundry tub, and floor drain system configurations.

Electrical Requirements

Grounding Instructions

Explains the importance and methods of grounding the appliance for safety.

Installation Instructions - Remove Transport System

Connect Inlet Hoses

Route Drain Hose

Secure Drain Hose & Level Washer

Complete Installation Checks

Features and Benefits

Key Washer Features

Details electronic controls, dispensers, suspension, and wash system.

Product Operation - Theory of Operation

System Components Overview

Explains the water system, inlet valves, flowmeter, and dispenser distribution.

Dispenser and Air Vent Systems

Pressure Switch Function

Component Locations and Functions

Tub Support and Eco Valve

Heating Element, Door Lock, and Interlocks

Washer Use Guide

Starting Your Washer

Provides initial steps for starting the washer and the first wash cycle.

Proper Detergent Usage

Advises on using High Efficiency (HE) detergents for optimal performance.

Using the Dispenser Drawer

Cycle Control and Status Lights

Cycle Operations and Indicators

Washer Cycles Overview

Introduces various wash cycles like Sanitary, Whitest Whites, and Heavy Duty.

Specific Wash Cycle Descriptions

Preset Cycle Settings Chart

Provides a chart of soil level, water temp, and spin speed for each cycle.

Wash Options and Modifiers

Temperature and Soil Level Controls

Guides on adjusting water temperature, soil level, and spin speed settings.

Laundry Guide Chart

Laundry Tips

Garment Care and Preparation

Offers recommendations for garment care, sorting, loading, and unloading.

Washer Care and Maintenance

Vacation, Storage, and Moving

Guidance on preparing the washer for non-use, freezing weather, or transport.

Troubleshooting Introduction

Error Code Display and Tone Sounds

Lists error codes (FH, F02, SUD, F) and initial troubleshooting steps.

Common Washer Problems - Draining, Noise, Leaks

Load-Related Issues

Addresses problems such as wet loads, residue, lint, and odor.

Troubleshooting - Stains, Wrinkles, Colors, Cycle Time

Door Lock and Imbalance Issues

Troubleshooting for the door remaining locked or load imbalance.

Component Access

Component Locations

Diagram showing the location of major internal components within the washer.

Removing Console and Touchpad/LED Assembly

Removing Door Lock, Front Panel, and Bellows

Removing the Flowmeter

Removing Detergent Dispenser Motor

Removing Inlet Valves

Removing the Central Control Unit (CCU)

Removing the Interference Filter

Removing the Pressure Switch

Removing the Motor Controller (MCU)

Removing Temperature Sensor and Heating Element

Removing the Drain Pump Assembly

Removing the Airtrap

Removing an Interlock Switch

Removing the Drive Motor

Removing the Tub and Basket Assembly

Component Testing Overview

Pressure Switch Testing

Procedure for testing the pressure switch resistance at various water levels.

Dispenser and Inlet Valve Testing

Door Lock/Switch Assembly Testing

Drain Pump and Interference Filter Testing

Heating Element and Temperature Sensor Testing

Drive Motor and Interlock Switch Testing

Diagnostics and Troubleshooting Guide

Diagnostic Guide Checks

Initial checks including power, fuses, faucets, and hose obstructions.

Failure/Error Display Codes - F/H

Error Codes F/02, F/05, F/06

Error Codes F/07, F/09, F/10

Error Codes F/11, F/13, F/14, F/15

Error Codes F/21, F/22, F/dU, F/dL

Suds Lock Error (Sud)

Diagnostic Test Procedure

Component Specific Tests

Manual Door Unlock System

Procedure for manually unlocking the washer door in emergencies.

Control Board Removal and Replacement

CCU Removal

Guides for removing the Central Control Unit (CCU).

Touchpad/LED Assembly Removal

Guides for removing the touchpad/LED assembly.

MCU Removal

Guides for removing the Motor Control Unit (MCU).

Interference Filter Removal

Guides for removing the interference filter.

Troubleshooting Chart - Power and Cycle Start Issues

Troubleshooting - Will Not Power Up

Lists causes and tests for the washer not powering up.

Troubleshooting - Will Not Start Cycle

Lists causes and tests for the washer not starting a cycle.

Troubleshooting Chart - Cycle Shutoff and Control Input

Troubleshooting - Will Not Dispense

Troubleshooting for the washer not dispensing properly.

Troubleshooting - Will Not Fill

Troubleshooting for the washer not filling properly.

Troubleshooting Chart - Overfills, Drum Rotation, Overheating

Troubleshooting - Over Fills

Addresses issues like overfilling.

Troubleshooting - Drum Will Not Rotate

Troubleshooting for drum rotation issues.

Troubleshooting - Motor Overheats

Troubleshooting for motor overheating.

Troubleshooting Chart - Draining, Vibration, Temperature, Display

Troubleshooting - Will Not Drain

Troubleshooting for draining issues.

Troubleshooting - Machine Vibrates

Troubleshooting for machine vibration.

Troubleshooting - Incorrect Water Temperature

Troubleshooting for incorrect water temperature.

Troubleshooting - Display Is Flashing

Troubleshooting for flashing displays.

Wiring Diagram

Support and Warranty Information
