Typical tools needed for installation:
– PTFE tape
– Jointing compound
– Cutting knife
– Pipe wrench
– Adjustable spanners
– Spirit level
– Screwdrivers
– T20 security Torx screwdriver
– Duct tape (heat resistant)
WARNINGS: Read these instructions carefully before you start, and make sure you have everything
necessary for proper installation. These instructions cover both gas or electric dryer stacked on top of
the electric washer.
Proper installation is the responsibility of the owner. This appliance must be installed in accordance with
these Maytag installation instructions, and all local and national regulations, such as for electrical wiring,
municipal buildings, gas fitting. For Australia the installation should also be carried out in accordance
with the AGA Installation Code for gas burning appliances. Maytag gas dryers have been certified for
operation on either Natural Gas or LP Gas (with appropriate conversion).
Service calls performed as a result of incorrect installation may be the responsibility of the installer.
These instructions should be left with the owner for future reference.
If disposing of an old dryer or washer, remove the door(s) to prevent it being a hazard to young children.
Page 1
Gas Washer/Dryer Only
CONTENTS:
1. Before you start 8. Gas connection
2. Space requirements 9. Water supply connection
3. Location 10. Drain hose connection
4. Unpacking 11. Commercial installation accessories
5. Door reversal 12. Final installation checklist
6. Dryer exhaust 13. Technical specification
7. Electrical connection
1. Before you start
Items provided with your washer/dryer:
Electric Washer/Dryer Only
Gas Adapter
