© 1998 Maytag Corporation
16008373-01 SECTION 1. GENERAL INFORMATION
1-13
CYCLE REVIEW
Main Wash Time/Total Cycle Time - Minutes (See Notes).
Notes:
1. The main wash times listed include 2 minutes of bleach fill and tumble time.
2. The total cycle times are approximate and will vary based on water fill times, due to types of
clothing loads, available water pressure and the time for the door lock system to retract at
the end of the cycle.
3. The main wash time is affected significantly if the machine control detects an excessive
amount of suds. The washer will go into a suds reduction routine, consisting of a series of
additional rinse and partial drain cycles to reduce the suds present (See Troubleshooting &
Diagnosis - Clothes Wet at End of Spin).
Tumble Pattern - Number of seconds tumbling/Number of seconds of pause between tumbles.
N on-M ax
Extra ct Cotton/ Sturdy
Easy Care/
Perm Press Delicates
Hand
Washables
Heavy W ash 23 .0 /4 9.0 20 .0 /4 5.5 20/46.5 N ot A pplicable
Norm al Wash 17 .0 /4 3.0 14 .0 /3 9.5 14 .0 /4 0.5 Not A pplicable
Light/Quick
Wash
11 .0 /3 7.0 8.0/33.5 7.0/34.5 Not A pplicable
Fin al Spin
(RPM /M i n )
800/3.5 600/3.0 500/4.5 Not A pplicable
Max Extract
Cycles Cotton/ Sturdy
Easy Care/
Perm Press Delicates
Hand
Washables
Heavy W ash 23 .0 /4 6.0 20 .0 /4 1.5 20 .0 /4 2.0 20 .0 /4 3.0
Norm al Wash 17 .0 /4 0.0 14 .0 /3 5.5 14 .0 /3 6.0 14 .0 /3 7.0
Light/Quick
Wash
11 .0 /3 4.0 8.0/29.5 8 .0 /3 0.0 8 .0 /3 1.0
Fin al Spin
(RPM /M i n )
800/4.0 600/3.5 500/5.0 500/5.0
Cotton/ Sturdy Ea sy Care /
Perm Press
Delicates Hand Washables
7/3 5/3 6/24 3/27
