Maytag Neptune MAH3000 Service Manual

© 1998 Maytag Corporation
16008373-01 SECTION 4. CONSOLE
4-34-3
4-34-3
4-3
1.
Disconnect power to the unit.Disconnect power to the unit.
Disconnect power to the unit.Disconnect power to the unit.
Disconnect power to the unit.
2 . Carefully lift the timer knob and dial off
the timer shaft by pulling the knob away
from the face of the control console
(Figure 4-7).(Figure 4-7).
(Figure 4-7).(Figure 4-7).
(Figure 4-7).
3. Disengage the console assembly from
the top cover and roll forward
(See(See
(See(See
(See
Console Removal)Console Removal)
Console Removal)Console Removal)
Console Removal).
4. Remove timer mounting screw on back
of timer in the console.
5 . Slightly lift the locking tab on the back of
the timer
(Figure 4-8).(Figure 4-8).
(Figure 4-8).(Figure 4-8).
(Figure 4-8).
6 . With the locking tab lifted, slide the timer
body toward the end cap of the console.
This will disengage the retaining tabs of
the timer from the slots in the console.
7 . Lift the timer away from the console.
Figure 4-8Figure 4-8
Figure 4-8Figure 4-8
Figure 4-8
TIMER REMOVALTIMER REMOVAL
TIMER REMOVALTIMER REMOVAL
TIMER REMOVAL
Figure 4-7Figure 4-7
Figure 4-7Figure 4-7
Figure 4-7
REPLACEMENTREPLACEMENT
REPLACEMENTREPLACEMENT
REPLACEMENT
1 . Align the three tabs of the timer into the
slots of the console.
2 . Insert the timer into the slots and
slightly lift the locking tab of the timer.
Slide the timer away from the endcap
until the locking tab can engage with the
square hole in the console.
3. Replace mounting screw.
