Maytag Neptune MAH3000 Service Manual

© 1998 Maytag Corporation
16008373-01 SECTION 2. ELECTRICAL COMPONENTS & TESTING
2-6
FUNCTION
MACHINE
CONTROL
BOARD
TERMINAL/WIRE
MACHINE
CONTROL
BOARD
TERMINAL/WIRE
VOLTAGE-
APPROX.
(When Activated)
TIMER
CONTACT
Permanent Press
(Fabric Switch)
P5 (WH11) P3/2 (PK 37) 24 VDC Not Involved
Delicates
(Fabric Switch)
P5 (WH11) P3/6 (OR 38) 24 VDC Not Involved
Hand Wash
(Fabric Switch)
P5 (WH11) P3/8 (BR 39) 24 VDC Not Involved
Cotton/Sturdy
(Fabric Switch)
P5 (WH 11)
P5 (WH 11)
P5 (WH 11)
P3/2 (PK 37)
P3/6 (OR 38)
P3/8 (BR 39)
0 VDC
0 VDC
0 VDC
Not Involved
Signal ON/OFF
(Options Switch)
P5 (WH 11) P2/1 (PU 21) 24 VDC - ON
0 VDC - OFF
Not Involved
Extra Rinse
(Options Switch)
P5 (WH 11) P7/8 (PK 19) 120 VAC 12B, 6B,8T
Max Extract
(Options Switch)
P5 (WH 11) P2/3 (YL 20) 24 VDC Not Involved
Push To Start
Switch
(When pressed)
P5 (WH 11) P1/3 (RD 28) 120 VAC Not Involved
Unbalance
Control
P5 (WH11) P2/4 (OR 40) 24 VDC Not Involved
Door Lock - Spin P3 (1) P3/7 (YL 36) 24 VDC Not Involved
Motor Control &
Machine Control
P5 (WH11) LINE RELAY COM
(BK 27 or BK1)
120 VAC Not Involved
Hot Water Valve P5 (WH11) P7/1 (OR7) 120 VAC or
500-1000 Ohms
Not Involved
Cold Water Valve P5 (WH11) P7/2 (BU 9) 120 VAC or
500-1000 Ohms
Not Involved
Door Lock Wax
Motor
P5 (WH11) P7/4 (BR 14) 120 VAC Not Involved
Bleach Wax
Motor
P5 (WH11) Not Involved 120 VAC 2T
Softener Wax
Motor
P5 (WH11) Not Involved 120 VAC 2B
Delay Light P5 (WH11) Not Involved 120 VAC 4T
On Light
(Series 17)
P5 (WH11) P7/5 (RD 3) 120 VAC Not Involved
