MayTech MTSKR1905WF - Throttle and Brake Trigger Operation; Throttle Trigger Usage; Brake Trigger Usage; Speed Source Selection for Data Display

Maytech Waterproof Remote Control User Manual_20191012 by Eric and Eileen
7
/
17
Calibration interface
Quit Calibration process
Wheel diameter/Gear
ratio date setting
interface
Select One hundred / Ten / One / Decimal
place
Short press
one time
Main interface
Switch data display on main interface
Main menu and
sub-menu
Switch options in the menu
Data input interface
Data plus one
Short press
two time
Main interface
Relay switch suction and release
Short press
three time
Main interface
Transistor switch ON and OFF
9. Trottle and brake triggers operating instructions：
Operation
The other trigger
position
Current display
Throttle output
Press throttle
trigger
Brake trigger at
original position
Main interface
Output corresponding throttle signal
Press brake
trigger
Throttle trigger at
original position
Main interface
No throttle signal output
Throttle trigger not
at original position
Main interface of
ESK8 mode
Receiver outputs brake signal. The braking
force is determined by the position of the
brake trigger.
Throttle trigger
at 10%-100%
throttle position
Main interface of
ESURF mode
After 3 seconds, it enters the cruise speed
control mode, and the throttle keeps its
original output after release. The cruise
control will be cancelled when the brake
trigger is pressed again to the end or the
throttle trigger exceeds the cruise throttle
value.
10. Speed source：
Speed sginal is detected by motor phase wire or hall sensor wire or VESC. Please select 【Speed Source】
in remote manual Item6 and make sure hardware is connected correct and well. The original acquisition
speed signal is the electrical speed of the motor (ERPM). Then remote will convert it to RPM or Speed and
display.
Mode
Speed
Conversion formula
Esk8
Skateboard speed (KM/H)
ERPM/Motor Poles/Gear Ratio*60*3.14*Wheel Dia/1000000
Skateboard speed (MPH)
ERPM/Motor Poles/Gear Ratio*60*3.14*Wheel
Dia/1000000*0.6214
Esurf
Esurfboard propeller RPM (RPM)
ERPM/Motor Poles/Gear Ratio
11. Distance：
11.1 This function only works in Esk8 mode for electric skateboard.
