Disabling a damaged riser tube Troubleshooting
HeatMiser II Installation guide. © 2014, all rights reserved P a g e | 18
3 Spray the rubber sleeve with lubricant and pull it
over a 5/64" Allen Key.
Stretch and relax the rubber sleeve a number of
times over the 46/5" Allen key.
4 Gently push the rubber sleeve into the hole created
by the removal of the riser, until only the head is
showing.
5 Push the plastic repair plug firmly, all the way down
into the repair sleeve.
The hole is now plugged and will not leak.
7 Move the glazing to expose the risers on the other side of the panel.
8 Repeat steps 2 to 6 for the other end of the panel you just exposed.
9 Move back the glazing to its original position and re-attach the stoppers.
10 The panel is now leak free while its uniform appearance is restored.
6 Cut the riser tube so it fits exactly between the
broad heads of the plastic pins. Fit the riser onto the
stub of the repair plug.
