Installation instructions Open stand
HeatMiser II Installation guide. © 2014, all rights reserved P a g e | 9
3. Take 3 clasps; insert two into each
end of the glazing at the bottom of
the stand. Note: do not insert the
clasps into the outermost hole, but
the one next to it.
4. Insert the remaining clasp into the other end of the
unit; positioning it in the center of the panel.
Make sure the stands are stable on the ground.
6. Repeat steps 2 through 5 on the other panel.
7. Turn the solar collector so it is facing the sun.
5. Thread and tie the string through the hole of one of
the external clasps on the stand. Pull the string
towards the other side of the panel and thread it
through the clasp located there. Pull the string back to
the final clasp (on the stand) and tie it firmly in place.
