A/C /HEATER Cont’d
33 Flap, Vent¶-Serviced w/Blower Assy
34 Resistor¶ NA01-61-B15
¶Included w/Blower Assy
FRONT FENDER
1 Fender (HSLA) R NAY1-52-110
L NAY1-52-210
2
Liner, Fender R NA01-56-131A
L NA01-56-141C
3
Fastener, Liner (5/Side) R/L NA01-56-145
4
Clip, Liner Screw
(5/Side) R/L LA01-56-135
UNDERHOOD DIMENSIONS
FRONT INNER STRUCTURE
FRONT
Illustration Located in Next Column
1
Bar, Upper Tie 90-93 NA01-53-100F
94-97 NA75-53-100
2
Bar, Lower Tie NA01-53-16XC
3
Support, Latch NA01-56-221B
4
Bracket, Radiator R B61P-15-240A
L B61P-15-250A
5
Bracket, Stay R/L NA01-54-180
SIDE
1 Apron Assy (a) 90-93 R NAY1-53-200D
L NAY1-54-200D
94-97 R NAY1-53-200D
L NAY2-54-200
2
Panel, Apron¶ (a) R NA01-53-210F
L NA01-54-210G
(a) Use w/Part #B001-56-051
Cover¶ (b) B001-56-051
(b) As Required
3
Rail, Upper Front¶ R NA01-53-37Y
L NA01-54-37Y
4
Rail, Upper Rear¶ 90-96 R NA01-53-37ZB
L NA01-54-37ZA
97 R NA01-53-37ZB
L NA01-54-37ZD
5
Reinforcement¶ R NA01-53-380
L NA01-54-380B
6
Bracket, Air Cleaner¶
Left Side NA01-54-36X
7
Box, Torque¶ R NA01-53-391
L NA01-54-391
8
Bracket, Stabilizer¶ R N067-53-330
L N067-54-330
9
Reinf, Tie Down Hook¶ R NA01-53-32XB
L NA01-54-32XC
¶Included w/Apron Assy
10
Hook, Tie-Down R NA01-56-34XD
L NA01-56-34YD
11
Reinf, Apron R NA01-53-591
L NA01-54-590
12
Shield, Splash NA01-56-112
ELECTRICAL COMPONENTS
1 Block Assy, Main Fuse 90 NA01-66-760B
91-93 NA23-66-760
94 NA80-66-760
95-97 NB11-66-760
2
Cover, Fuse Block¶ 90 NA02-66-762B
91-93 NA23-66-762
94 NA80-66-762
95-97 NB11-66-762
¶Included w/Main Fuse Block Assy
CRUISE CONTROL SYSTEM
1 Actuator, Cruise Control LA01-66-310A
2
Brkt, Actuator Front NA01-66-3A3A
3
Brkt, Actuator Rear NA01-66-3A2A
4
Wire, Cruise Control NA01-66-311A
Clip, Cruise Control Wire
5 Front LA01-66-3A1
6 Rear UB39-61-479A
7
Control, Cruise NA01-66-320
AIR BAG SYSTEM
1990-94
1 Sensor, Outer R NA01-57-K2XK
L NA01-57-K2YK
2
Sensor, Center 90-93 NA01-57-K10H
94 NA75-57-K1XA
3
Cover, Outer Sensor R NA01-57-K45B
L NA01-57-K46B
4
Cover, Center Sensor NA01-57-K47C
Cover, Outer Sensor
5 Right NA01-56-191A
6 Left
w/o ABS NA01-56-181A
7
Sensor, Inner Air Bag NA01-57-K40D
Illustration Located in Next Column
8
Module, Driver Air Bag NA01-57-K00E-00
9
Module, Pass Air Bag 94 NAY5-57-K7X-00
10
Control Unit, Diagnosis
1990-93 NA01-67-7F0A
1994 GA2A-67-7F0A
11
Bracket, Control Unit R NA05-67-9A1B
L NA06-67-9A1B
12
Power Unit, Back-Up 90-93 NA01-67-7G0A
Clockspring¶-See Steering Wheel/Column Section
¶Serviced w/Combination Switch
