Mazda 3 2018 - Page 488

DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
19 ST HEATER 15 A
Heated steering wheel
*
20 AT 15 A Transaxle control system
21 R.WIPER 15 A
Rear window wiper
*
22 A/C 7.5 A Air conditioner
23 ENGINE3 15 A Engine control system
24 ENGINE2 15 A Engine control system
25 ENGINE1 15 A Engine control system
26 GLOW SIG 5 A ―
27 EVVT 20 A Engine control system
28 WIPER 20 A Front window wiper and washer
29 DCDC REG 30 A ―
30
EPB L
FUEL.P2
30 A
Electric parking brake (EPB) (LH)
*
31 ADD FAN DE 40 A ―
32 P.WINDOW1 30 A Power windows
33 H/L LOW R 15 A
Headlight low beam (RH)
*2
34 H/L LOW L HID L 15 A
Headlight (LH)
*1
, Headlight low beam (LH)
*2
35 METER1 10 A Instrument cluster
36 IG2 30 A For protection of various circuits
37
EPB R
LPG
30 A
Electric parking brake (EPB) (RH)
*
38
FUEL.P3
FAN DE
40 A ―
39 DCDC DE 40 A ―
40 SRS1 7.5 A Air bag
41 ENGINE. IG1 15 A Engine control system
42 C/U IG1 15 A For protection of various circuits
43 METER3 10 A ―
*
1 With LED headlights
*
2 With halogen headlights
Maintenance and Care
Owner Maintenance
6-60
*Some models.
