Mazda 3 2018 - Page 607

(Mexico)
Tire size
Inflation pressure
Front Rear
P205/60R16 91H 250 kPa (2.5 bar, 36 psi) 250 kPa (2.5 bar, 36 psi)
Tire size
Inflation pressure
Up to 3 persons ―Full load
215/45R18 89W
Front 240 kPa (2.4 bar, 35 psi) 280 kPa (2.8 bar, 41 psi)
Rear 230 kPa (2.3 bar, 33 psi) 300 kPa (3.0 bar, 44 psi)
1 person's weight: About 75 kg
Temporary spare tire
Tire size Inflation pressure
T125/70D16 96M 420 kPa (60 psi)
Lug nut tightening torque
When installing a tire, tighten the lug nut to the following torque.
108—147 N･m (12—14 kgf･m, 80—108 ft･lbf)
▼
Fuses
Refer to Fuses on page 6-57.
Specifications
Specifications
9-11
