Instrument Cluster
7 8
Low Fuel Level
KEY
KEY Warning Light (RED)
Advanced key not detected
or transmitter battery is dead.
KEY
KEY Indicator Light (GREEN)
On:Advancedkeydetected;engine
is ready to start.
Flashing:Advancedkeybatteryislow.
Check Fuel Cap
ABS (Antilock Brake
System) Malfunction
Lights On (Exterior)
Tire Pressure
Monitoring System
(TPMS) Warning Light
On/WarningBeep:Lowtire
pressure in one or more tires.
Flashing:TPMSMalfunction
TCS
OFF
TCS OFF
(Traction Control System)
Charging System Malfunction
Powertrain Malfunction/
Reduced Power
BSM
OFF
BSM OFF
(Blind Spot Monitoring)
Check Engine Light
Brake Warning Light
Parkingbrakeon/lowbrake
uid/malfunction
Turn Signals/Hazard
Warning Indicator Lights
Automatic Transmission
Malfunction
Shift Position Indicator Light
Headlight High Beams On
Traction Control System
(TCS)/Dynamic Stability
Control (DSC)
On:TCS/DSCmalfunction
Flashing:TCS/DSCoperating
Air Bag/Front Seat Belt
Pretensioner System
Malfunction
Low Engine Oil Pressure
Security Indicator Light
Door/Liftgate Ajar
4WD
4WD
On:Systemisnotnormal;dealer
inspectionrequired.
Flashing:Differentialoiltemperature
ishigh;dealerinspectionrequired.
Seat Belt
Unbuckled/Malfunction
Cruise Main Indicator
Light On (AMBER)/
Cruise Set Indicator
Light On (GREEN)
Low Washer Fluid Level
TACHOMETER
FUEL GAUGE
SPEEDOMETER
TRIP METER
SELECTOR
2
INSTRUMENT
CLUSTER DIMMER
1
ENGINE COOLANT
TEMPERATURE GAUGE
ODOMETER/
TRIP METER
SHIFT LEVER
POSITION INDICATOR
GLOSSARY OF WARNING AND INDICATOR LIGHTS
NOTE: SeeOwner’sManualformoredetailsandexplanations.
NOTE: Low ambient temperature and/or high altitude causes tire pressures to drop
andmayturntheTPMSwarninglighton.Ifthewarninglightcomeson,checkthetire
pressureandllthetiresassoonaspossible,preferablybeforemovingthevehicleand
warmingupthetires.Tirepressureshouldbecheckedwhenthetiresarecold.
1
If the instrument cluster and other dashboard illuminations do not dim when turning on the headlights,
push the Instrument Cluster Dimmer knob.
2
•PushtotogglebetweentripmeterA&B.
 •Whenatripmeterisselected,pushandholdtoresettozero.
Theinstrumentclusterhasadimmerfunctionthat
can be cancelled to make the illumination brighter
during the day when the headlights are on. If
the illumination is too dim during the day,
press the knob, or if the illumination does
not dim when turning on the headlights
at night, press the knob.
Whendimmed,rotatethe
knob to adjust the brightness
of the illumination.
