DESCRIPTION
FUSE
RATING
PROTECTED COMPONENT
17 D.LOCK 20 A Power door lock
18 P.WIND 20 A Power window
19 TCM 15 A Transaxle control system
20 HEAD HI 20 A Headlight high beam
21
10 A Engine control system
22 STOP 10 A Brake lights
23 FUEL PUMP 20 A Fuel system
24 HAZARD 10 A Hazard warning flasher, Direction indicator lights
25 ROOM 15 A Interior lights
26 ENG FAN 15 A Cooling fan
27 A/C MAG 10 A Magnet clutch
28 HORN 15 A Horn
29 AUDIO1 15 A Audio system
30 DCDC3 25 A For protection of various circuits
31 ABS V 20 A ABS
32 TAIL 15 A Tail lights, Position lights, Number plate lights, Rear fog light
í
33 ILLUMI 7.5 A Illumination
34 ENG INJ 25 A Engine control system
35 ENG BAR 15 A Engine control system
36 ―― ―
37 ―― ―
38 DEFOG 25 A Rear window defroster
39 HEAD LO L 15 A Headlight low beam (LH)
40 HEAD LO R 15 A Headlight low beam (RH)
8-46
Maintenance and Care
í
Some models.
