Suspension
! Trapezoidal front suspension tower bar adopted to improve the rigidity and handling stability. (MT)
! 19-inch wheel and tire adopted for hard suspension.
AT
MT
FRONT SUSPENSION
TOWER BAR
FRONT SUSPENSION
TOWER BAR
TRANSVERSE MEMBER
FRONT SHOCK ABSORBER
AND COIL SPRING
FRONT UPPER ARM
FRONT STABILIZER
CONTROL LINK
FRONT LOWER ARM
FRONT
STABILIZER
FRONT
CROSSMEMBER
