CONTROL SYSTEM [13B-MSP]
01-40–9
01-40
End Of Sie
DRIVE-BY-WIRE RELAY CONTROL OPERATION [13B-MSP]
id0140g1170800
Idle Speed Control
x Controls the throttle valve opening angle so that it is close to the target idle speed calculated by the PCM.
x The PCM calculates the target throttle opening angle by adding each type of correction to the basic duty value
which is the basis of the throttle valve opening angle, and then sends a duty signal to the throttle valve actuator.
The basic duty value is determined by the target engine speed.
x Each type of correction is as follows.
APV motor ×
Fuel injector (FP, FS) ×
Fuel injector (RP, RS) ×
Fuel pump relay ×
Fuel pump speed control
relay
×
Ignition coil (T/F, T/R) ×
Ignition coil (L/F,L/R) ×
Air solenoid valve ×
Air pump relay ×
Purge solenoid valve ×
Metering oil pump driver ×
Metering oil pump No.1, No.2 ×
OCV ×
A/F sensor heater ×
HO2S heater ×
A/C relay ×
Cooling fan relay No.1, No.2,
No.3, No.4, No.5
×
Starter relay ×
Generator (terminal D: field
coil)
×
CAN ×
Item
MAIN RELAY CONTROL
DRIVE-BY-WIRE RELAY CONTROL
DRIVE-BY-WIRE CONTROL
S-DAIS CONTROL
FUEL INJECTION CONTROL
FUEL PUMP CONTROL
FUEL PUMP SPEED CONTROL
ELECTRIC SPARK ADVANCE CONTROL
AIR CONTROL
EVAPORATIVE PURGE CONTROL
METERING OIL PUMP CONTROL
OIL PRESURE CONTROL
A/F SENSOR HEATER, HO2S HEATER CONTROL
A/C CUT-OFF CONTROL
ELECTRICAL FAN CONTROL
STARTER CUT-OFF CONTROL
GENERATOR CONTROL
CAN
