unique high end audio
mbl 6010 D
12
7. Options (modules)
All installations must be performed exclusively by your MBL dealer.
7.1 Balanced-In
The Balanced-In module contains an active balancing stage for connecting a balanced signal to the preamplifier
inputs.
Balanced:
2 = + In Phase
3 = - Out of Phase
1 = Ground, 0 V
7.2 Phono
An absolute must for the analog record enthusiast - the Phono-MC-Module. The Phono-MC-Module features a
separate RIAA equalizer for optimum adjustment and the RIAA poles are distributed to multiple amplifiers, thus
increasing the amplification headroom of each amplifier and reducing distortion to almost zero. At a gain reserve
of 12 dB it still results in an incredible overload resistance of 24 dB! The deviation from the RIAA curve is less than
0.2 dB.
The Phono-MC-Module can optionally be installed at one of the provided spaces of the Input group A.
