MBM 93M - Page 18

Adjustment
17
Adjust stopper plate position
Single Fold
Deviations of stopper plate from label indicator
A. too long A. too short
A. too long A. too short
B. too long B. too short
A、B、C not up to standard
Double Fold
1.First adjust the 1st
fold plate according to
single opposite folding
method, adjust to 1/2 of
the paper length.
2.Then adjust the 2nd
fold plate, use label
indicator as
benchmark, relative to
paper thickness slightly
move the stopper plate,
adjust to standard.
