- 19 -
ITEM PART NO. DESCRIPTION
F36/4
F46/4
1. 01169 GREASE FITTING, 45 44
2. 01258 SPRING 44
3. 01280 SOCKET HEAD SHOULDER SCREW, 3/8” x 3/8” 4
4. 22731 YOKE PLATE ASM. 11
5. 05330 PRESSURE PLATE, 4-ARM* 1 1
6. 05331 SPIDER, 4-ARM (includes 15)* 1 1
7. 05397 BOLT, HOLLOW 44
8. 05402 COMBINATION BLADE, 8” x 14” 4
05412 COMBINATION BLADE, 8” x 18” 4
9. 05492 CAP, GREASE 44
10. 06459 BUSHING, SPLIT 88
11. 06755 TILT ARM, 36” (includes 15 & 20) 4
07850 TILT ARM, 46” (
includes 15 & 20) Serial number 1470019 & lower and 1470130 & up. 4
21368 TILTARM, 46, (includes items 15 & 20) Serial number 1470020 thru 1470129.
4
12. 17190 CARRIAGE BOLT, (SPECIAL) 3/8-16 x 1-1/4” LG. 4 4
13.
21230
STABILIZER RING 1
14.
F051812HC
HEX HEAD CAP SCREW, 5/16-18 x 1-1/2” 8 16
15. F05LW LOCKWASHER, 5/16” 816
16.
F061614SH
SQUARE HEAD SET SCREW, 3/8-16 x 1-3/4” 1 1
17. F0616HN HEX NUT, 3/8-16 44
18. F06LW LOCKWASHER, 3/8” 44
REPLACEMENT KITS
01427 GREASE FITTING CAPS (sold in sets of 12) 5
06199
Kit, Spider (include 1, 2, 6, 7, 9, 11, 12. 16, 17 & 18)
1
07898
Kit, Spider (includes 1, 2, 6, 7, 9, 11, 12, 16, 17 & 18) Serial #1470019 & lower and #1470130 & up.
1
21369
Kit, Spider (includes 1, 2, 6, 7, 9, 11, 12, 16, 17 & 18) Serial #1470020 thru #1470129.
1
