MBW F36/4 - Page 32

- 29 -
ITEM PART NO. DESCRIPTION F36 F46
1. 01291 CABLE TIE 11
2. 05381 CABLE ASSEMBLY, (Includes items #34 & #36) 1 1
3. 05395 PIVOT PIN 11
4. 07592 SPLICE TERMINAL 11
5. 07774 SHORTING WIRE ASM 11
6. 15991 LOCK WASHER, 1/4” INTERNAL TOOTH 1 1
7. 16040 COMPRESSING SPRING 1 1
8. 16078 CLIP BEARING 22
9. 16081 LEVER ARM 11
10. 16083 LOCK DOG 11
11. 16086 SHAFT, ACTIVATING 11
12. 21109 GRIP 22
13. 21585 CABLE SLIDE 1
14. 21712 STRUT MOUNT 11
15. 21713 GEAR ASSEMBLY, WELDED 1 1
16. 21716 HANDLE LINK 22
17. 21718 GAS SPRING 11
18. 21724 LEVER, EZ PITCH 11
19. 21725 HEX HEAD SCREW SCREW, #12-34 x 1/2 2 2
20. 22215 SAFETY SWITCH ASSEMBLY (Includes item #6) 1 1
21. 22440 HANDLE CENTER TUBE 1 1
22. 22434 THROTTLE ASM 11
23. 22437 HANDLE BAR 11
24. 22445 HANDLE HEIGHT ADJUSTMENT LEVER, 3/8-16 1 1
25. 22585 TRIGGER PULL 11
26. 22586 DOWEL PIN, 3/16 x 5 11
27. 22587 RETAINING RING, E-STYLE, 3/16 2 2
28. 22794 SCREW, BINDING, 1/4 3/4 LG. 2 2
29. F0312RP ROLL PIN, 3/16 x 1-1/2 33
30. F032403HCS HEX HEAD SCREW, #10-24 X 3/8 LG. 2 2
31. F042003BCS BUTTON HEAD SCREW, 1/4-20 x 3/8 ZP 1 1
32. F04SW WASHER, 1/4 22
33. F051818HCS HEX HEAD SCREW. 5/16-18 X 2-1/4 GR 5 ZP 2 2
34. F0518ELN NYLOC LOCKNUT, 5/16-18 3 3
35. F0518FN FLANGE LOCK NUT, 5/16-18 1 1
36. F0518HN HEX NUT, 5/16-18 11
37. F05SW WASHER, 5/16 44
38. F061640HCS HHCS, 3/8-16 x 5, GR5, ZP 1 1
UK HANDLE ASSEMBLY:
39. 21071 HANDLE “DEADMAN”, UK 1 1
40. 21076 WIRRE HARNESS, “DEADMAN” HANDLE, UK 1 1
41. 21110 HANDLE GRIP, “DEADMAN”, UK 1 1
REPLACEMENT PARTS:
16080 LEVER ARM ASSEMBLY (includes items 7, 9, 10, 25, 26 & 27)
21721 F36 TROWELHANDLE ASSEMBLY (includes all above except item #4)
21720 F46 TROWEL HANDLE ASSEMBLY (includes all above except item #4)
