30107-10 Rev. 2.5 | 24NOV2020
Page 3
Ultra Mag Flow Meter Specications
Speci cation Sheet
Ultra Mag Flow Meter with ProComm Converter
30107-09 Rev. 5.1 | 11MAY2020
Page 5
FLOW METER SPECIFICATIONS
Pipe Sizes
2”, 3”, 4”, 6”, 8”, 10”, 12”, 14”, 16”, 18”, 20”, 24”, 30”, 36”, 42”, 48”
Flow Direction Measurement
Forward and reverse ow indication and forward, reverse, net totalization are standard with
all meters
Accuracy
Plus or minus 0.5% of actual ow (battery powered is ±1% of ow)
IMPORTANT NOTICE ON FLOW METER ACCURACY: The ow meter, the cable and the
electronics are factory calibrated for accuracy as a single unit. Changing the cable length with
the Splice Kit changes the accuracy of the meter and invalidates the calibration certi cate.
Accuracy Tests
5-point wet ow calibration of every complete ow tube with its signal converter. If desired,
the tests can be witnessed by the customer. The McCrometer test facilities are traceable to
the National Institute of Standards & Technology. Uncertainty relative to ow is ±0.15%
Pipe Run Requirements
2” & 3” wafer style 3D upstream / 1D downstream
2” and larger anged 1D upstream / 0D downstream
Repeatability
±0.05% or ±.0008ft/s (±0.25mm/s), whichever is greater
Conductivity
5 µs/cm
Liner
UltraLiner NSF approved, fusion bonded epoxy
Electrodes
Type 316 stainless steel, others optional
Electrical Connections
• Compression gland seals
• Quick-Connect
IP Rating
Standard model • Quick Connect (NEMA 6P/IP68 with remote converter)
• Compression gland seals (NEMA 6P/IP68 with remote converter)
HL model • Quick Connect (IP67)
• Compression gland seals (IP67)
Sensor Submersibility Depth
With standard strain
relief cable
9 m (30 ft.)
With optional quick
connect cable
1.8 m (6 ft.)
