McGraw 64857 - Parts List and Diagram

Page 18 @+-*)/93='91<*A,/()'+=(B*4</1(/*91<<*CD###D#!!D$%E%6 Item 64857
FG@;HI JK;LGHMJN OGMNH;NGNP;MNFHGQQGHMJN
K1-)(*Q'()*1=>*U'18-1:
K1-)(*Q'()
K1-) U/(9-'4)'+= k)V
1 Plug 1
2 Shroud 1
3 Snap Ring 1
4 Fan 1
5 Bolt M5x117 4
6 Spring Washer 4
7 Washer 4
8 Bolt M5x16 16
9 Washer 10
10 Coupling Assembly 1
11 Front Cover 1
12 Coupling Assembly 1
13 Bearing 1
14 Rotor Assembly 1
15 Thermal Protector 1
16 Bearing 1
17 Stator 1
18 Oil Seal 1
19 Nut M8 3
20 Spring Washer 3
21 Block 2
22 Bolt M8x20 2
23 Crank Case 1
24 Bolt M3x6 2
25 Locking Washer 2
26 Nut M3 2
27 Capacitor 1
28 O-Ring 2
29 Bolt M8x16 1
30 Capacitor Bracket 1
31 Coupling Assembly 1
32 Bolt M6x25 3
33 Nut M6 3
34 Crank Shaft 1
35 Connecting Rod 1
36 Piston 1
37 Oil Ring 1
38 Piston Ring 2
39 Gasket 1
40 Cylinder 1
41 Spring Washer 2
42 Bolt M8x30 2
43 Seal 1
44 Valve Plate 2
45 Reed Valve 1
46 Reed Valve 1
47 Seal 1
48 Air Filter 1
49 Bolt M6x50 4
50 Spring Washer 8
51 Washer 4
52 Start Valve 1
K1-) U/(9-'4)'+= k)V
53 Cylinder Cap 1
54 Elbow 1
55 Snap Ring 2
56 Piston Pin 1
57 Rubber Seal 1
58 End Cover 1
59 Oil Breather 1
60 O-Ring 1
61 Bolt M6x20 4
62 Oil Glass 1
63 Bolt M5x10 1
64 O-Ring 1
65 Coupling Assembly 1
66 Nut 2
67 Funnel 2
68 Nut 1
69 Check Valve 1
70 Funnel 2
71 Nut 1
72 End Cap 5
73 Tube 1
74 Power Switch 1
75 Safety Valve 1
76 Nut 2
77 Connecting Joint 2
78 O-Ring 2
79 Handle Plug 2
80 Wire 1
81 Power Cord 1
82 Cooling Fins 1
83 Air Tube 1
84 Bolt M5x12 1
85 Washer 1
86 Gauge Cover 1
87 Pressure Gauges 1
88 Coupler 1
89 Pressure Regulator 1
90 Regulator Knob 1
91 Screw 1
92 Rubber Grip 1
93 Tank Assembly 1
94 Wheel 2
95 Washer 2
96 Bolt M12x60 2
97 Sleeve 2
98 Spring Washer 2
99 Nut 2
100 Drain Valve 1
101 Foot 2
102 Washer 2
103 Bolt M8x25 2
