1� Check the oil level before operation�
Fill the Pump Crankcase with included
SAE 30W, non-detergent, Air Compressor Oil�
MOKJLHGNH2 L,=='=8*)3/*G'-*P+:4-/((+-*
.')3*=+*+'<*+-*<+.*+'<*.'<<*91,(/*>1:18/*)+*
)3/*/A,'4:/=)*1=>*W+'>*)3/*.1--1=)V6
2� The oil level should be at the center of the “full” level
on the Oil Sight Glass�
Add oil as needed to maintain this level�
Do not let the oil level go below
the center dot and do not overfill the oil
so that it is above the center dot�
J'<*
T-/1)3/-
J'<*
F'83)*
S<1((
J&;L@MQQ
QJR
@[QQ
3� To add oil:
a� Remove the Oil Breather�
b� Using a funnel to avoid spills, pour enough
oil into the Pump Crankcase to reach
the “full” level in the Oil Sight Glass�
c� Replace the Oil Breather�
N+)/2 SAE 30W, non-detergent,
Air Compressor Oil (sold separately) is
recommended for use with this compressor�
4� If uncertain which oil to use for this compressor,
call Harbor Freight Tools customer service
at 1-888-866-5797 for assistance�
5� P31=8/*)3/*9+:4-/((+-*+'<*17)/-*)3/*7'-()*
3+,-*+7*,(/*)+*-/:+W/*1=V*>/0-'(6
