McHale
991B
Round Bale Wrapper
56
9
Wrapper Operation
9.1 Preparing the machine for wrapping
1. Load the plastic film into the dispenser running it through the rollers as shown
in Figure 9.c. Attach the film to the bale. See “Loading plastic film” on page 57.
2. Turn on the oil supply.
3. Unlock the transport lock, so that it is as shown in Figure 9.a. Do not attempt
to lower the bale lift arm with the transport lock still engaged.
4. Lower the bale lift arm to the ground (if fitted).
5. Lower the bale damper (if fitted).
6. Switch on the electronic control box and set to “Automatic” mode (Electronic
models).
7. Connect the bale wrap computer (Manual control models).
8. Ensure the table is in the correct starting position (see “Electronic Control Box
Functions” on page 45). On electronic machines, the control box needs to be
set on “manual” to work this function.
9. The machine is now ready to wrap.
WARNING: Keep out of the “Danger Zone”
Keep all persons outside of the “Danger Zone” during all machine
operations! See “Danger Zone” on page 14.
ENVIRONMENT: Recycling of the plastic film
Respect the environment! Never dump or burn waste plastic film. It’s
toxic! Always take waste materials to a recycling centre.
Figure 9.a - Transport lock, unlocked Figure 9.b - 991B Machine
